| Type | 1700 EX | 1700 EXB |
|---|---|---|
| Max. working height | 16.8 m | 16.8 m |
| Max. outreach | 9.1 m | 9.1 m |
| Max. basket load | 200 kg | 200 kg |
| Basket size | 1.25 x 0.8 x 1.1 m | 1.25 x 0.8 x 1.1 m |
| Basket rotation | ±50° | 50° |
| Turret rotation | ±355° | 355° |
| Travelling length | 6.25 m | 6.25 m |
| Travelling height | 1.99 m | 1.99 m |
| Travelling width | 1.66 m | 1.66 m |
| Operational width | 4.12 m | 4.12 m |
| Power supply | 230 V / 16 A | – |
| Battery (maintenance-free) | – | 24 V / 180 Ah / 5h |
| Charger | – | 24 V / 30 A |
| Total weight | 2060 kg | 2200 kg |
