- Basket capacity: 250 kg (2 op.)
- Basket size: 1.50 x 1.20 m
- Max working height: 7.9 m
- Max height basket floor: 5.9 m
- Moving height: 6.0 m
- Accelerator: Automatic
- Undercarriage: Bi-Levelling
- Basket levelling: Automatic
- Longitudinal levelling Front: +/- 16°
- Longitudinal levelling Rear: +/- 20°
- Lateral levelling: +/- 15°
- Electric pump (option): 220V-2,2kW
- Direction-Control System: Yes
- Easy-Drive System: Yes
- Max speed: max 2.20 km/h
- Ground emergency: Yes
- Control of inclination: Automatic
- Gradeability: 25°
- Side slope: 21°
- Length: 1.94 m
- Width: 1.30 ÷ 1.50 m
- Min height with narrow tracks: 2.28 (1.98) m
- Min height with wide tracks: 1.98 (1.68) m
- Compliance: EN 280, ANSI, CSA, AS/NZS
- Powered: Gasoline Honda iGX390
- Powered (option): Diesel Hatz 1B40
- Total weight with Gasoline Honda iGX390: 2500 kg
- Total weight with Diesel Hatz 1B40: 2530 kg
