| Type | Mini 15 EXJ | Mini 15 EXBJ |
|---|---|---|
| Max. working height | 14.6 m | 14.6 m |
| Max. outreach | 8.3 m | 8.3 m |
| Max. basket load | 125 kg | 125 kg |
| Basket size | 0.85 x 0.7 x 1.1 m | 0.85 x 0.7 x 1.1 m |
| Basket rotation | ± | — |
| Turret rotation | ±355° | 355° |
| Travelling length | 6.05 m | 6.05 m |
| Travelling height | 1.94 m | 1.94 m |
| Travelling width | 1.52 / 1.05 m | 1.52 / 1.05 m |
| Operational width | 3.65 m | 3.65 m |
| Power supply | 230 V / 10 A | – |
| Battery (maintenance-free) | – | 24 V / 110 Ah / 5h |
| Charger | – | 24 V / 15 A |
| Total weight | 1500 kg | 1500 kg |
