| Type | 2650 iRXB Battery | 2650 iRXD Diesel | 2650 iRXBD Hybrid |
|---|---|---|---|
| Max. working height | 26.5 m | 26.5 m | 26.5 m |
| Max. outreach | 12.2 m | 12.2 m | 12.2 m |
| Max. basket load | 136 kg | 136 kg | 136 kg |
| Basket size | 0.80 × 0.65 m | 0.80 × 0.65 m | 0.80 × 0.65 m |
| Basket rotation | ±90° | ±90° | ±90° |
| Turret rotation | ±355° | ±355° | ±355° |
| Travelling length | 10.24 m | 10.24 m | 10.24 m |
| Travelling height | 2.42 m | 2.42 m | 2.42 m |
| Travelling width | 1.50 / 1.10 m | 1.50 / 1.10 m | 1.50 / 1.10 m |
| Operational width | 5.32 / 4.59 m | 5.32 / 4.59 m | 5.32 / 4.59 m |
| Battery (maintenance-free) | 24 V / 360 Ah / 5h | – | 24 V / 180 Ah / 5h |
| Charger | 24 V / 30 A | – | 24 V / 30 A |
| Diesel engine | – | 18.5 kW / 24.8 hp | 18.5 kW / 24.8 hp |
| Generator | – | 24 V / 22 A | 24 V / 22 A |
| Total weight | 6075 kg | 6075 kg | 6075 kg |
| Gradeability, max. across slope up to | 35% / 19.3° | 35% / 19.3° | 35% / 19.3° |
| Gradeability, max. up and down slope | 35% / 19.3° | 35% / 19.3° | 35% / 19.3° |
| Deployment ability on slopes up to | – | – | – |
