- Basket Capacity: 300 kg (2 operators)
- Basket Size: 1.80 × 1.30 m
- Max Working Height: 10.0 m
- Max Height Basket Floor: 8.0 m
- Moving Height: 6.5 m
- Accelerator: Automatic
- Undercarriage: Bi-Levelling
- Basket Levelling: Automatic
- Longitudinal Levelling Front: ±15°
- Longitudinal Levelling Rear: ±20°
- Lateral Levelling: ±14°
- Electric Pump (Option): 220V – 2.2 kW
- Direction-Control System: Yes
- Easy-Drive System: Yes
- Ground Emergency: Yes
- Control of Inclination: Automatic
- Gradeability: 25°
- Side Slope: 21°
- Width: 1.46 ÷ 1.64 m
- Min Height with Narrow Tracks (Folded Railings): 2.42 (2.08) m
- Min Height with Wide Tracks (Folded Railings): 2.09 (1.75) m
- Compliance: EN 280, ANSI, CSA, AS/NZS
- Power: N°2 Electric Motors – Total Power 10.6 kW
- Power Pack ELC: Lead Crystal 180Ah 48V
- Power Pack LTH: Lithium 210Ah 48V
- Total Weight ELC: 3050 kg
- Total Weight LTH: 2880 kg
- Max Speed: 4.50 km/h
