| Type | 2100 E | 2100 EB | 2100 EBD Hybrid |
|---|---|---|---|
| Max. working height | 21.2 m | 21.2 m | 21.2 m |
| Max. outreach | 12.2 m | 12.2 m | 12.2 m |
| Max. basket load | 200 kg | 200 kg | 200 kg |
| Basket size | 1.25 x 0.8 x 1.1 m | 1.25 x 0.8 x 1.1 m | 1.25 x 0.8 x 1.1 m |
| Basket rotation | ±41° | 41° | 41° |
| Turret rotation | ±355° | 355° | 355° |
| Travelling length | 7.39 m | 7.39 m | 7.61 m |
| Travelling height | 2.07 m | 2.07 m | 2.07 m |
| Travelling width | 1.70 m | 1.70 m | 1.70 m |
| Operational width | 4.25 m | 4.25 m | 4.25 m |
| Power supply | 230 V / 16 A | – | – |
| Battery (maintenance-free) | – | 24 V / 180 Ah / 5h | 24 V / 180 Ah / 5h |
| Charger | – | 24 V / 30 A | 24 V / 30 A |
| Diesel engine | – | – | 14 kW / 18.8 hp |
| Generator | – | – | 24 V / 22 A |
| Total weight | 2380 kg | 2500 kg | 2825 kg |
