| Type | 3150 RBJ Battery | 3150 RBDJ Hybrid |
|---|---|---|
| Max. working height | 31.1 m | 31.1 m |
| Max. outreach | 12.6 m | 12.6 m |
| Max. basket load | 200 kg | 200 kg |
| Basket size | 1.25 × 0.8 × 1.1 m | 1.25 × 0.8 × 1.1 m |
| Basket rotation | ±41° | ±41° |
| Turret rotation | ±355° | ±355° |
| Travelling length | 8.29 / 7.54 m | 8.29 / 7.54 m |
| Travelling height | 1.99 m | 1.99 m |
| Travelling width | 1.10 m | 1.10 m |
| Operational width | 4.59 / 3.72 m | 4.59 / 3.72 m |
| Battery (maintenance-free) | 24 V / 360 Ah / 5h | 24 V / 180 Ah / 5h |
| Charger | 24 V / 30 A | 24 V / 30 A |
| Diesel engine | – | 14 kW / 18.8 hp |
| Generator | – | 24 V / 22 A |
| Total weight | 4000 kg | 4000 kg |
| Gradeability, max. across slope up to | 25% / 14.0° | 25% / 14.0° |
| Gradeability, max. up and down slope | 35% / 19.3° | 35% / 19.3° |
| Deployment ability on slopes up to | 40% / 21.8° | 40% / 21.8° |
