| Type | 3710 RBJ Battery | 3710 RBDJ Hybrid |
|---|---|---|
| Max. working height | 37.0 m | 37.0 m |
| Max. outreach | 13.7 m | 13.7 m |
| Max. basket load | 250 kg | 250 kg |
| Basket size | 1.25 × 0.8 × 1.1 m | 1.25 × 0.8 × 1.1 m |
| Basket rotation | ±41° | ±41° |
| Turret rotation | ±355° | ±355° |
| Travelling length | 8.04 / 7.44 m | 8.04 / 7.44 m |
| Travelling height | 1.99 m | 1.99 m |
| Travelling width | 1.50 / 1.10 m | 1.50 / 1.10 m |
| Operational width | 4.78 / 3.86 m | 4.78 / 3.86 m |
| Battery (maintenance-free) | 24 V / 360 Ah / 5h | 24 V / 360 Ah / 5h |
| Charger | 24 V / 30 A | 24 V / 30 A |
| Diesel engine | – | 18.5 kW / 24.8 hp |
| Generator | – | 24 V / 22 A |
| Total weight | 5700 kg | 5700 kg |
| Gradeability, max. across slope up to | 35% / 19.3° | 35% / 19.3° |
| Gradeability, max. up and down slope | 35% / 19.3° | 35% / 19.3° |
| Deployment ability on slopes up to | 30% / 16.7° | 30% / 16.7° |
