| Type | 25.00 RXDJ Diesel | 25.00 RXBDJ Hybrid |
|---|---|---|
| Max. working height | 25.0 m | 25.0 m |
| Max. outreach | 12.8 m | 12.8 m |
| Max. basket load | 200 kg | 200 kg |
| Basket size | 1.25 x 0.8 x 1.1 m | 1.25 x 0.8 x 1.1 m |
| Basket rotation | ±41° | 41° |
| Turret rotation | ±355° | 355° |
| Travelling length | 6.53 m / 5.76 m | 6.91 m / 6.16 m |
| Travelling height | 1.99 m | 1.99 m |
| Travelling width | 1.38 m / 0.89 m | 1.38 m / 0.89 m |
| Operational width | 4.84 m / 3.67 m | 4.84 m / 3.67 m |
| Battery (maintenance-free) | – | 24 V / 180 Ah / 5h |
| Charger | – | 24 V / 30 A |
| Diesel engine | 14 kW / 18.8 hp | 14 kW / 18.8 hp |
| Generator | 24 V / 22 A | 24 V / 22 A |
| Total weight | 4065 kg | 4200 kg |
| Gradeability, max. across slope up to | Wide 30% (16.7°) / Narrow 20% (11.3°) | Wide 30% (16.7°) / Narrow 20% (11.3°) |
| Gradeability, max. up and down slope | 30% / 16.7° | 30% / 16.7° |
| Deployment ability on slopes up to | 40% / 21.8° | 40% / 21.8° |
| Power Pack | Diesel | Hybrid |
