- Max Capacity: 1500 kg (<25°)
- Max Capacity Crane: 990 kg
- Max Longitudinal Gradient in Translation: ±22°
- Max Lateral Gradient in Translation: ±10°
- Max Longitudinal Gradient in Crane Use: ±10°
- Max Lateral Gradient in Crane Use: ±5°
- Width: 890 mm
- Length: 2170 mm
- Height: 1900 mm
- Track Length: 1230 mm
- Track Width: 250 mm
- Ground Clearance: 170 mm
- Platform Ground Height: 830 mm
- Max Speed: 4.2 km/h
- Power of Electric Motors: 10.6 kW
- Ingress Protection IP: IP67
- Controller: Remote Radio Control
- Electric Pump for Crane and AUX: 48V – 4.5 kW
- Tow Hook: Standard
- Rear Pothole: Standard
- Lateral Potholes: Optional
- Non-Marking Tracks: Optional
- Winch KIT: Optional
- Work Lights: Optional
- Voltage: 48 V
- Battery Pack (180Ah): AGM
- Charger Input & Time (110V–230V): 32A 48V / 9h
- Total Weight: 2000 kg
