| Type | 4200 RBJ Battery | 4200 RBDJ Hybrid |
|---|---|---|
| Max. working height | 42.0 m | 42.0 m |
| Max. outreach | 15.2 m | 15.2 m |
| Max. basket load | 230 kg | 230 kg |
| Basket size | 1.25 × 0.8 × 1.1 m | 1.25 × 0.8 × 1.1 m |
| Basket rotation | ±41° | ±41° |
| Turret rotation | ±355° | ±355° |
| Travelling length | 8.93 / 8.33 m | 8.93 / 8.33 m |
| Travelling height | 1.99 m | 1.99 m |
| Travelling width | 1.75 / 1.35 m | 1.75 / 1.35 m |
| Operational width | 5.33 / 4.53 m | 5.33 / 4.53 m |
| Battery (maintenance-free) | 24 V / 360 Ah / 5h | 24 V / 360 Ah / 5h |
| Charger | 24 V / 30 A | 24 V / 30 A |
| Diesel engine | – | 18.5 kW / 24.8 hp |
| Generator | – | 24 V / 22 A |
| Total weight | 6900 kg | 6900 kg |
| Gradeability, max. across slope up to | 27% / 15.0° | 27% / 15.0° |
| Gradeability, max. up and down slope | 30% / 16.7° | 30% / 16.7° |
| Deployment ability on slopes up to | 27% / 15.0° | 27% / 15.0° |
