- Technical Data: JIBBI 1890 PRiMO
- Max Working Height: 17.90 m
- Max Height Basket Floor: 15.90 m
- Max Moving Height: 13.80 m
- Max Outreach (Load 140 kg): 9.92 m
- Max Outreach (Load 250 kg): 8.32 m
- Rotation Angle: ±190°
- Basket Size: 1.80 × 0.70 m
- Basket Rotation Angle: ±70°
- Max Basket Capacity: 250 kg (2 persons)
- Length in Stowed Position: 5.86 m
- Width: 2.20 m
- Min Height in Stowed Position: 2.16 m
- Longitudinal Leveling: ±15.6°
- Lateral Leveling: ±15.6°
- Max Gradeability: 25°
- Max Side Gradeability: 25°
- Drive Speed (Fast): 3.60 km/h
- Drive Speed While at Height: 0.60 km/h
- Anti-Entrapment System: Yes
- Traffic Load (Load in Basket 140 kg):
- ELC: 4.91 kN/m²
- LTH 330Ah: 4.59 kN/m²
- LTH 440Ah: 4.60 kN/m²
- LTH 660Ah: 4.60 kN/m²
- Total Weight:
- ELC: ~6310 kg
- LTH 330Ah: ~5890 kg
- LTH 440Ah: ~5910 kg
- LTH 660Ah: ~5900 kg
- Main Power Source:
- Lead Acid Power Pack 420Ah – 48V
- Lithium Power Pack 330Ah – 48V
- Lithium Power Pack 440Ah – 48V
- Lithium Power Pack 660Ah – 48V
- Re-Charging Time (Output Current 65A at 230V; 25A at 85V):
- ELC: 8 h at 230V
- LTH 330Ah: 5.0 h at 230V
- LTH 440Ah: 6.5 h at 230V
- LTH 660Ah: 10.0 h at 230V
- N°1 Battery Charger 85–265V 50/60Hz 65A Max – Automatic Setting: Yes
- N°2 Electric Gearmotors 7.5 kW 48V Each (IP67): Yes
- Electric Pump 4.5 kW 48V: Yes
- Non-Marking Tracks: Yes
- Kit Works Lights: Yes
- Arctic Lubricant for Cold Climate: Yes
- Ultrasonic Anti-Collision System: Yes
